Customer-replaceable units 111
Customer-replaceable units
NOTE: The following tables share the table endnotes located beneath them. See Figure 77 (page 115) for
pictorial views of IOM CRUs used in the different Lenovo ThinkSystem enclosures.
1-This model uses a qualified FC SFP option within the CNC ports (used for host connection). When in FC mode, the SFPs must be a qualified
8Gb or 16Gb fiber-optic option. A 16Gb/s SFP can run at 16Gb/s, 8Gb/s, 4Gb/s, or auto-negotiate its link speed. An 8Gb/s SFP can run at
8Gb/s, 4Gb/s, or auto-negotiate its link speed.
2-This model uses a qualified 10GbE iSCSI option within the controller module CNC ports (used for host connection).
3-This model uses a qualified 1 Gb iSCSI SFP option within the controller module CNC ports (used for host connection).
4-CNC ports support same-type or mixed-type SFPs in combination as described in “CNC ports used for host connection” (page 13).
5-This model uses SFF-8644 connectors and qualified cable options for host connection.
Table 23 DS6200 enclosure models
Lenovo ThinkSystem DS6200: 4-port controller
enclosure matrix
2.5" (SFF) 24-drive controller enclosures
Model Description Form
DS6200 Fibre Channel (8/16Gb/s) SFP
1,4
2U24
DS6200 Internet SCSI (10GbE) SFP
2,4
2U24
DS6200 Internet SCSI (1Gb/s) SFP
3,4
2U24
DS6200 HD mini-SAS (12Gb/s)
5
2U24
Table 24 DS4200 enclosure models
Lenovo ThinkSystem DS4200: 4-port controller enclosure matrix
2.5" (SFF) 24-drive controller enclosures 3.5" (LFF) 12-drive controller enclosures
Model Description Form Model Description Form
DS4200 Fibre Channel (8/16 Gb/s) SFP
1,4
2U24 DS4200 Fibre Channel (8/16 Gb/s) SFP
1,4
2U12
DS4200 Internet SCSI (10GbE) SFP
2,4
2U24 DS4200 Internet SCSI (10GbE) SFP
2,4
2U12
DS4200 Internet SCSI (1 Gb/s) SFP
3,4
2U24 DS4200 Internet SCSI (1 Gb/s) SFP
3,4
2U12
DS4200 HD mini-SAS (12 Gb/s)
5
2U24 DS4200 HD mini-SAS (12 Gb/s)
5
2U12
Table 25 DS2200 enclosure models
Lenovo ThinkSystem DS2200: 2-port controller enclosure matrix
2.5" (SFF) 24-drive controller enclosures 3.5" (LFF) 12-drive controller enclosures
Model Description Form Model Description Form
DS2200 Fibre Channel (8/16Gb/s) SFP
1
2U24 DS2200 Fibre Channel (8/16Gb/s) SFP
1
2U12
DS2200 Internet SCSI (10GbE) SFP
2
2U24 DS2200 Internet SCSI (10GbE) SFP
2
2U12
DS2200 Internet SCSI (1Gb/s) SFP
3
2U24 DS2200 Internet SCSI (1Gb/s) SFP
3
2U12
DS2200 HD mini-SAS (12Gb/s)
5
2U24 DS2200 HD mini-SAS (12Gb/s)
5
2U12
