Replacing a drive carrier module 125
Installing a SFF drive carrier module
1. Release the carrier handle by pressing the latch in the handle downwards, and opening the hinged handle as
shown in Figure 87 (page 125). Insert the carrier into the enclosure in a vertical position.
IMPORTANT:
Make sure the carrier is positioned such that the disk is on its left side and the handle opens from
the top.
Figure 87 SFF drive carrier module in open position
