Technical data
General data and operating conditions
4

42
EDS84DPS424 EN 5.0
Mounting conditions
Mounting place Wall
Ensure convection cooling in the niches.)
Mounting position
Standard mounting
Display to the front
Vertically suspended, −30 ... +30 °
In case of greater angles of tilt:
Operation at 2/4 kHz: > +40 °C: Reduce the rated output
current by 2.5 %/°C.
Operation at 8/16 kHz: > +35 °C: Reduce the rated output
current by 2.5 %/°C.
Free space  72
Requirements on the motor cable
Capacitance per unit length
 1.5 mm
2
/AWG 16 C
Core/core
/C
Core/shield
 75/150 pF/m
 2.5 mm
2
/AWG 12 C
core/core
/C
Core/shield
 100/ 150 pF/m
Electric strength
VDE 0250−1 U
0
/U
=
0.6/1.0 kV
(U
0
= r.m.s. value external − conductor/PE,
U = r.m.s. value − external conductor/external
conductor)
UL U  600 V
(U = r.m.s. value external conductor/external
conductor)
