Technical data
General data and operating conditions
4
43
EDS84DPS424 EN 5.0
EMC
Noise emission
Cable−guided
EN 61800−3
Up to 20 m shielded motor cable (Lenze system cable):
category C2
Radiation Category C2
Noise immunity (according to requirements of EN 61800−3)
Electrostatic discharge
(ESD)
EN 61000−4−2 8 kV with air discharge,
4 kV with contact discharge against housing
Radio frequency
Cable−guided EN 61000−4−6 150 kHz ... 80 MHz, 10 V/m 80 % AM (1kHz)
Interference (housing) EN 61000−4−3 80 MHz ... 1000 MHz, 10 V/m 80 % AM (1kHz)
Burst
Power terminals and
interfaces
EN 61000−4−4 2 kV/5 kHz
Signal interfaces EN 61000−4−4 1 kV/5 kHz
Control terminals EN 61000−4−4 2 kV/5 kHz
Surge
Power terminals EN 61000−4−5 1.2/50 s,
1 kV phase/phase, 2 kV phase/PE
Control terminals EN 61000−4−5 1.2/50 s, 1 kV
Operation on public supply
systems
EN 61000−3−2
EN 61000−3−12
The devices are intended for use in an industrial
environment. When being used on public network,
additional measures must be taken to limit the expected
radio interference. The compliance with the requirements for
the machine/plant is the responsibility of the manufacturer
of the machine or system!
EN 61000−3−2
< 0.5 kW: with mains choke
0.5 ... 1 kW: with active filter
> 1 kW at mains current 16 A: No limit values for harmonic
currents
EN 61000−3−12 Mains current > 16 A: further measures are required for
compliance with the standard
