5 Motor control & motor settings
5.8 Setting the motor parameters for the servo control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Subindex 4: Motor: Rated speed
Setting range (min. value | unit | max. value) Lenze setting
0 r/min 50000 4050 rpm
 Write access  CINH  OSC  P  RX  TX UNSIGNED_16
Subindex 5: Motor: Rated frequency
Setting range (min. value | unit | max. value) Lenze setting
0.0 Hz 1000.0 270.0 Hz
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 UNSIGNED_16
Subindex 6: Motor: Rated power
Setting range (min. value | unit | max. value) Lenze setting
0.00 kW 655.35 0.25 kW
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 UNSIGNED_16
Subindex 7: Motor: Rated voltage
Setting range (min. value | unit | max. value) Lenze setting
0 V 65535 225 V
 Write access  CINH  OSC  P  RX  TX UNSIGNED_16
Subindex 8: Motor: Rated cosine phi
Setting range (min. value | unit | max. value) Lenze setting
0.00 655.35 0.80
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 UNSIGNED_16
Subindex 9: Motor: Insulation class
see also motor equivalent circuit
The axis command 0x2822:0 / 0x3022:0 = 3 serves to derive the scaled warning and switch-off thresholds of the
motor temperature monitoring from the parameterised insulation class.
Observe the following for applications with third-party and special motors:
There may be constellations where warning and switch-off thresholds (0x2D49:3
/ 0x3549:3 or 0x2D49:4 /
0x3549:4
) correspond to a low insulation class. A manual parameter setting at the end of the motor commissioning
is required here.
Example
The winding design corresponds to the insulation class H, the switch-off temperature, however, is already reached
at ϑ = 155° C.
Selection list (Lenze setting printed in bold)
0 Y (cut-off temperature = 90°C)
1 A (cut-off temperature = 105 °C)
2 E (cut-off temperature = 120°C)
3 B (cut-off temperature = 130°C)
4 F (cut-off temperature = 155°C)
5 H (cut-off temperature = 180°C)
6 G (cut-off temperature > 180°C)
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
Subindex 10: Motor: Designation
 Write access  CINH  OSC  P  RX  TX STRING(50)
