0x2B02 | 0x3302 - VFC: User-definable V/f characteristic - frequency grid points (x)
0x2B03 | 0x3303 - VFC: User-definable V/f characteristic - voltage grid points (y)
Sub. Name Lenze setting Data type
1 V/f: x1 = f01 -50 Hz INTEGER_16
2 V/f: x2 = f02 -40 Hz INTEGER_16
3 V/f: x3 = f03 -30 Hz INTEGER_16
4 V/f: x4 = f04 -20 Hz INTEGER_16
5 V/f: x5 = f05 -10 Hz INTEGER_16
6 V/f: x6 = f06 0 Hz INTEGER_16
7 V/f: x7 = f07 10 Hz INTEGER_16
8 V/f: x8 = f08 20 Hz INTEGER_16
9 V/f: x9 = f09 30 Hz INTEGER_16
10 V/f: x10 = f10 40 Hz INTEGER_16
11 V/f: x11 = f11 50 Hz INTEGER_16
 Write access  CINH  OSC  P  RX  TX
Sub. Name Lenze setting Data type
1 V/f: y1 = U01 (x = f01) 400.00 V UNSIGNED_32
2 V/f: y2 = U02 (x = f02) 320.00 V UNSIGNED_32
3 V/f: y3 = U03 (x = f03) 240.00 V UNSIGNED_32
4 V/f: y4 = U04 (x = f04) 160.00 V UNSIGNED_32
5 V/f: y5 = U05 (x = f05) 80.00 V UNSIGNED_32
6 V/f: y6 = U06 (x = f06) 0.00 V UNSIGNED_32
7 V/f: y7 = U07 (x = f07) 80.00 V UNSIGNED_32
8 V/f: y8 = U08 (x = f08) 160.00 V UNSIGNED_32
9 V/f: y9 = U09 (x = f09) 240.00 V UNSIGNED_32
10 V/f: y10 = U10 (x = f10) 320.00 V UNSIGNED_32
11 V/f: y11 = U11 (x = f11) 400.00 V UNSIGNED_32
 Write access  CINH  OSC  P  RX  TX
