7 CiA402 device profile
7.9 Cyclic sync velocity mode (csv)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.9.1 Default mapping
The default mapping for the cyclic sync velocity mode is defined in the following objects:
Date received from the controller (RPDO)
Data transmitted to the controller (TPDO)
Object Name Data type
Axis A Axis B
0x1602 0x1612 RPDO-->Axis A/B: Cyclic sync velocity mode (csv) RECORD
0x1606
0x1616 RPDO-->Axis A/B: Torque limits RECORD
0x1A02
0x1A12 Axis A/B-->TPDO: Cyclic sync velocity mode (csv) RECORD
Object Name Data type
Axis A Axis B
0x6040 0x6840 Controlword UNSIGNED_16
0x2830
0x3030 Lenze control word UNSIGNED_16
0x6060
0x6860 Operating mode: Selection INTEGER_8
0x60B2 0x68B2 Torque offset INTEGER_16
0x60FF
0x68FF Target velocity INTEGER_32
0x60E0
0x68E0 Positive torque limit value UNSIGNED_16
0x60E1
0x68E1 Negative torque limit value UNSIGNED_16
Object Name Data type
Axis A Axis B
0x6041 0x6841 Statusword UNSIGNED_16
0x2831 0x3031 Lenze status word UNSIGNED_16
0x6061 0x6861 Modes of operation display INTEGER_8
0x603F 0x683F Error code UNSIGNED_16
0x606C 0x686C Velocity actual value UNSIGNED_16
0x6077 0x6877 Torque actual value INTEGER_16
0x6064 0x6864 Position actual value INTEGER_32
