10 Service/internal
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x2DD4 | 0x35D4 - Speed controller: Output signal
0x2DD5 | 0x35D5 - torque: Target torque
0x2DD6 | 0x35D6 - Torque: Filter cascade
-480000 r/min 480000 0 rpm
 Write access  CINH  OSC  P  RX  TX INTEGER_32
Subindex 3: Speed: target speed limited
Display area (min. value | unit | max. value) Initialisation
-480000 r/min 480000 0 rpm
 Write access  CINH  OSC  P  RX  TX INTEGER_32
Subindex 2: Speed: target speed 2
•100% ≡ rated motor torque (0x6076 or 0x6876 for axis B)
Sub. Name Lenze setting Data type
1 Speed controller: Output signal 1 0.0 % INTEGER_16
2 Speed controller: Output signal 2 0.0 % INTEGER_16
Subindex 1: speed controller: output signal 1
Display area (min. value | unit | max. value) Initialisation
-3276.7 % 3276.7 0.0 %
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 2: speed controller: output signal 2
Display area (min. value | unit | max. value) Initialisation
-3276.7 % 3276.7 0.0 %
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
•100% ≡ rated motor torque (0x6076 or 0x6876 for axis B)
Display area (min. value | unit | max. value) Initialisation
-21474836.47 Nm 21474836.47 0.00 Nm
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 INTEGER_32
•100% ≡ rated motor torque (0x6076 or 0x6876 for axis B)
Sub. Name Lenze setting Data type
1 Torque: Filter cascade - starting value 0.0 % INTEGER_16
2 Torque: Notch filter 1 - input value 0.0 % INTEGER_16
3 Torque: Notch filter 2 - input value 0.0 % INTEGER_16
4 Torque: Target torque filtered 0.0 % INTEGER_16
