Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 134
5 Motor control & motor settings
5.12 Fine adjustment des motor model
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x2C05 | 0x3405 - Motor: Lss saturation charcteristic - reference for current grid points (x)
Sub. Name Lenze setting Data type
1 Lss: y1 = L01 (x = 0.00 %) 165 % UNSIGNED_16
2 Lss: y2 = L02 (x = 6.25 %) 200 % UNSIGNED_16
3 Lss: y3 = L03 (x = 12.50 %) 146 % UNSIGNED_16
4 Lss: y4 = L04 (x = 18.75 %) 117 % UNSIGNED_16
5 Lss: y5 = L05 (x = 25.00 %) 97 % UNSIGNED_16
6 Lss: y6 = L06 (x = 31.25 %) 82 % UNSIGNED_16
7 Lss: y7 = L07 (x = 37.50 %) 71 % UNSIGNED_16
8 Lss: y8 = L08 (x = 42.75 %) 62 % UNSIGNED_16
9 Lss: y9 = L09 (x = 50.00 %) 55 % UNSIGNED_16
10 Lss: y10 = L10 (x = 56.25 %) 50 % UNSIGNED_16
11 Lss: y11 = L11 (x = 62.50 %) 46 % UNSIGNED_16
12 Lss: y12 = L12 (x = 68.75 %) 43 % UNSIGNED_16
13 Lss: y13 = L13 (x = 75.00 %) 42 % UNSIGNED_16
14 Lss: y14 = L14 (x = 81.25 %) 41 % UNSIGNED_16
15 Lss: y15 = L15 (x = 87.50 %) 41 % UNSIGNED_16
16 Lss: y16 = L16 (x = 93.25 %) 41 % UNSIGNED_16
17 Lss: y17 = L17 (x = 100.00 %) 41 % UNSIGNED_16
18 Motor: Lss saturation characteristic -
Activation
1: Active UNSIGNED_16
 Write access  CINH  OSC  P  RX  TX
Maximum motor current
• Serves as a reference value for the scaled current values of the X axis of the saturation characteristic.
Setting range (min. value | unit | max. value) Lenze setting
0.0 A 500.0 5.4 A
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 UNSIGNED_16
