8 Monitoring functions
8.3 Monitoring of the heatsink temperature
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.3 Monitoring of the heatsink temperature
In order to avoid impermissible heating of the device, the heatsink temperature is detected and
monitored.
0x2D84 | 0x3584 - Heatsink temperature
Subindex 5: Device utilisation (Ixt): Warning threshold
Setting range (min. value | unit | max. value) Lenze setting
0 % 101 95 %
 Write access  CINH  OSC  P  RX  TX UNSIGNED_16
Subindex 6: Device utilisation (Ixt): Error threshold
Display area (min. value | unit | max. value) Initialisation
0 % 101 101 %
 Write access  CINH  OSC  P  RX  TX UNSIGNED_16
 Note!
In the temperature range 0 ... 80 °C, the heatsink temperature is measured with a
tolerance of -2 ... +4 °C. Outside this temperature range, the measuring accuracy
strongly decreases.
Sub. Name Lenze setting Data type
1 Heatsink temperature: Actual temperature INTEGER_16
2 Heatsink temperature: Warning threshold 80.0 °C INTEGER_16
3 Heatsink temperature: Threshold - switch-on
fan
55.0 °C INTEGER_16
4 Heatsink temperature: Threshold - switch-off
fan
45.0 °C INTEGER_16
Subindex 1: Heatsink temperature: Actual temperature
Display of the current heatsink temperature
Display area (min. value | unit | max. value) Initialisation
-3276.8 °C 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 2: Heatsink temperature: Warning threshold
Warning threshold for temperature monitoring
• If the heatsink temperature exceeds the threshold value set here, the device reports a warning. The warning
message is reset with a hysteresis of approx. 5 °C.
• If the heatsink temperature increases further and exceeds the non-adjustable error threshold (100 °C), the
device changes to the "Fault" device status. Further operation of the i700 servo inverter is disabled by controller
inhibit.
Setting range (min. value | unit | max. value) Lenze setting
50.0 °C 100.0 80.0 °C
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
