Applications
Leuze electronic RSL 430 48
1
2
6
5
3
4
1 Warning field for forward travel
2 Protective field 1 for forward travel, deactivated
3 Protective field 2 for forward travel, activated
4 Protective field 1 for reverse travel, activated
5 Protective field 2 for reverse travel, deactivated
6 Warning field for reverse travel
Fig.6.5: Mobile danger zone guarding
