Lexmark C543dn - Page 162

4-14 Service Manual
5025-2xx, 4xx
Go Back
Previous
Next
7. Remove the machine screws (C), and remove the ground cable from the cover.
8. Lift and slide the paper stop to expose the screw (D), and remove the screw.
