Parts catalog 7-15

5056-XXX

Assembly 9: Base 3

Index P/N Units Description

9 — 1 40X1067 1 Clutch, MPF

9 — 2 40X1085 1 Switch, turn guide

9 — 3 40X1040 1 Clutch, registration

9 — 4 40X1113 1 Cable, registration clutch

9 — 5 40X1116 1 Cable, MPF clutch

9 — 6 40X1115 1 Cable, registration sensor

9 — 7 40X1115 1 Cable, registration sensor

9 — 8 40X1137 1 Photo interruptor

9 — 9 40X1136 1 Photo interruptor

9 — 10 56P2671 1 Sensor, upper OHP

9 — 11 56P2669 1 Frame assembly, MPF

9 — 12 40X1154 1 Frame assembly, registration

9 — 13 40X1114 1 Cable, carrying clutch

9 — 14 40X1040 1 Clutch, registration (used on carrying frame)

9 — 15 56P9683 1 Roller assembly, carrying

9 — 16 40X1025 1 Frame assembly, carrying

9 — 17 40X1041 1 Unit, transfer belt

9 — 18 40X1209 1 Guide assembly, fuser entry

9 — 19 40X1152 1 Sensor, density

9 — 20 40X1155 2 Frame assembly, F1 sub

9 — 21 56P9685 2 Frame assembly, F2 sub

9 — 22 56P9686 1 Rod, lock

9 — 23 56P9687 1 Cover, gear

9 — 24 40X1156 1 Stopper, clutch

NS 56P9697 1 Bushing

NS 40X1266 Parts packet
