3 Remove the three screws (A) and the bezel (B).
A
B
4 Remove the control panel assembly.
Control panel assembly removal (MS622de and MS622dte)
1 Remove the right cover. See “Right cover removal” on page 186.
2 Remove the nameplate. See “Nameplate removal” on page 201.
3 Remove the three screws (A) and the bezel (B).
B
A
4 Open the front door.
4600-830, -835, -895
Parts removal
203
