Lexmark M3250

3 Remove the duplex. See “Duplex assembly removal” on page 218.
4 Position the printer on its left side.
5 Remove the spring (A) and the two screws (B).
B
A
B
6 Disconnect the cable, and then remove the sensor.
4600-830, -835, -895
Parts removal
223
