Connector Connects to Pin no. Signal
JMTR1 Motor (main) 1 MAIN_HALL_U_CN
2 MAIN_HALL_V_CN
3 MAIN_HALL_W_CN
4MAIN_FG_CN
5Ground
65V_ENG
7V_MAINC1_U
8V_MAINC1_V
9V_MAINC1_W
JWIFI1 Wireless network 1 Ground
2 NC_USB_DP
3 NC_USB_DM
4Ground
5USB_WIFI_P_CN
6USB_WIFI_N_CN
7Ground
8 no connection
9 ISP_RESET-
10 5V
11 SDA_ISP
12 5V
13 SCL_ISP
14 5V_WIFI
M1 Ground
M2 Ground
JRESET1 not used ‑‑ not used
JCVR1 Cover open 1 V_5V_INDEX
2 S_INDEX_C
3Ground
JINDEX1 Sensor (stack height) 1 V_5V_INDEX
2 S_INDEX_C
3Ground
JSTAG1 Staging solenoid ‑‑ not used
4600-830, -835, -895
Component locations
