Lexmark M3250 Service Manual

Assembly 3: Electronics 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1185 1 1 Printhead
“Printhead removal” on
page 239
2 41X1178 1 1 Fuser, 110V
“Fuser removal” on
page 234
2 41X1179 1 1 Fuser, 220V
“Fuser removal” on
page 234
2 41X1180 1 1 Fuser, 100V
“Fuser removal” on
page 234
3A 41X1195 1 1 Controller board (MS622)
• This part is the original board for
old printers (8th digit of printer
serial number=0, or 1).
• This part can be installed on
new printers (8th digit of printer
serial number≥2). Firmware
update is required.
“Controller board removal”
on page 194
3B 41X2512 1 1 Controller board (MS622)
• This part is the original board for
new printers (8th digit of printer
serial number≥2).
• This part can be installed on old
printers (8th digit of printer
serial number=0, or 1). The
control panel flat cable
(41X2526) also needs to be
installed.
“Controller board removal”
on page 194
3B 41X1194 1 1 Controller board (MS621)
“Controller board removal”
on page 194
4 41X1201 1 1 Power supply, 100V/110V
“Power supply removal” on
page 216
4 41X1202 1 1 Power supply, 220V
“Power supply removal” on
page 216
5 41X1224 1 1 Main drive gearbox
“Main drive gearbox
removal” on page 178
4600-830, -835, -895
Parts catalog
264

Lexmark M3250 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Printing colors	Black
Maximum duty cycle	175000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Number of print cartridges	1
Page description languages	-
Paper input type	Paper tray
Total input capacity	650 sheets
Total output capacity	250 sheets
Maximum input capacity	2300 sheets
Maximum number of input trays	4
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
USB connector	USB Type-A / USB Type-B
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Processor cores	2
Processor frequency	1000 MHz
Sound pressure level (printing)	55 dB
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	EPEAT Silver, ENERGY STAR
Power consumption (printing)	- W
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business

Weight and Dimensions

Depth	373.4 mm
Width	398.8 mm
Height	302.3 mm
