Assembly 4: Electronics 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1989 1 1 Pick/lift motor
gearbox
“Pick/lift motor gearbox removal” on
page 232
2 41X2259 1 1 Cooling fan
“Cooling fan removal” on page 190
3 41X1214 1 1 Reverse solenoid
“Reverse solenoid removal” on page 183
4 41X1237 1 1 Cartridge gearbox
“Cartridge gearbox removal” on page
184
5 41X1213 1 1 MPF solenoid
“MPF solenoid removal” on page 185
4600-830, -835, -895
Parts catalog
266
