Assembly 6: Electronics 4
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1208 1 1 Sensor (trailing edge)
“Sensor (trailing edge) removal” on
page 226
241X1206 1 1Sensor (duplex and
input)
“Sensors (duplex and input) removal”
on page 220
3 41X1238 1 1 Sensor (paper present)
“Sensor (paper present) removal” on
page 224
4 40X8800 1 1 Paper present sensor
flag
“Paper present sensor flag removal” on
page 228
5 40X8046 1 1 Sensor (toner density)
“Sensor (toner density) removal” on
page 222
6 40X8044 1 1 Sensor (index)
“Sensor (index) removal” on page 222
4600-830, -835, -895
Parts catalog
270
