Assembly 10: Optional trays
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 41X1216 1 1 Optional 550-sheet tray --
1 41X1217 1 1 Optional 250-sheet tray --
241X12391 1Pick roller --
3 41X1222 1 1 550-sheet tray insert (optional tray) --
3 41X1221 1 1 250-sheet tray insert (optional tray) --
4 41X1212 1 1 Separator roller assembly
“Separator roller assembly
removal” on page 242
4600-830, -835, -895
Parts catalog
278
