Repair information 4-7
4060-xxx
M3x6 mm Taptite outer shield mounting 6
inner redrive deflector mounting 2
interconnect board to center pan mounting 2
system board to interconnect board ground attach 2
system board to inner shield mounting 2
system board (back) mounting 2
lower stacker duct mounting 1
ground cables to ground (center pan—front) attach 1
cable clip (main drive gearbox, BTM) mounting 2
M3x8 mm Taptite LVPS mounting 2
autocompensator hanger bracket mounting 1
M3x6 mm Taptite
Panhead
stacker duct mounting 1
system board to shield mounting 2
system board mounting 2
shield ground attach 1
LVPS mounting 2
fuser cover mounting 2
cable clip mounting 2
outer shield mounting 6
INA cover mounting 1
M3x12 mm Taptite
Panhead
HVPS board mounting 2
Reference
number
Screw type Location Purpose Qty
To Next Page
