Lexmark T632 - Page 234

5-16 Service Manual
4060-xxx
J34 Paper size sensor 1 PSIZE2
2Ground
3 PSIZE1
4 PSIZE3
5Ground
6 TRAY1 POUT
7 TRAY1 PLOW*
8 +3.3V dc
autocomp motor 9 ENCODER
10 +5V dc
J35 System board edge
connector
J36 (not used)
J37 (not used)
J40 SDRAM (on board)
System board—non-network and network (see “System board—non-network” on page 5-10 or “System
board—network” on page 5-11)
Connector Pin no. Signal
