Lexmark T632 - Page 233

Connector locations 5-15
4060-xxx
J25 Autocomp motor 1 +5V_TRAY1
2 +5v_SWITCHED
3 PAPER_OUT-IN
4 AUTOCOMP_ENC
5 PAPER_LOW_IN
6Ground
7Ground
8Ground
9 AUTOCOMP_OUT1
10 AUTOCOMP_OUT2
J26 MPF paper out 1 MPF POUT
2Ground
3MPF LED
J27 (not used)
J28 Autocompensator 1 +24V dc
internal tray 2 AutoComp*
J29 Bottom options 1 RXD1R
2Ground
3TXD1BR
4Ground
J30 (not used)
J31 top options 1 RXD1R
2Ground
3TXD1BR
4Ground
J32 MPF pick solenoid 1 MPFPick*
2 +24V dc
J33 Ethernet connector
System board—non-network and network (see “System board—non-network” on page 5-10 or “System
board—network” on page 5-11)
Connector Pin no. Signal
