Parts catalog 7-57
4060-xxx
Assembly 26: High-capacity output expander
Asm-
Index
Part
Number
Units Description
26-1 99A1748 2 Door asm, rear access
2 99A1785 4 Latch, rear door
3 99A1783 1 Frame, right
4 99A1778 2 Pulley, output tray
5 99A1782 2 Shaft, pulley
6 99A1790 2 Guide, output tray
7 99A1779 2 Spring, output tray
8 99A1746 1 Cover, right
9 99A1747 1 Cover, front
10 99A1701 1 Tray asm, output
11 99A1781 1 Frame, left
12 99A1666 1 Label, options
13 99A1745 1 Cover, left
NS 99A1751 1 Switch asm, tray sensing
NS 99A1777 1 Flag, tray sensing switch
NS 99A1780 2 Gear, damping
NS 99A1744 2 Kit, high-capacity output stacker
