Parts catalog 7-59
4060-xxx
Assembly 26 (cont.): High-capacity output expander
Asm-
Index
Part
Number
Units Description
26-29 99A0913 2 Shaft, 40T middle output stacker
30 99A0368 2 Shaft asm lower
31 99A0363 6 Pulley, drive
32 99A0361 1 Belt, 160G upper stacker asm
33 99A0362 1 Arm asm, belt idler
34 99A0364 2 Spring, belt tensioner
35 99A1791 1 Stacker asm, paper path lower
35 99A1792 1 Stacker, asm paper path upper
36 99A0351 2 Sensor, stacker pass thru
NS 99A1751 1 Switch asm
NS 99A0462 1 Packet grease, IBM #23
NS 99A0627 1 Jumper, 2 pin (use with 99A1749)
