Liebert Vertiv GXT5 User Manual

Specications106
MODEL GXT5- 750IRT2UXL* 750IRT2UXLE 1000IRT2UXL* 1000IRT2UXLE
RATING 750 VA/750 W 1000 VA/1000 W
Environmental Requirements
Operating Temperature,
°F (°C)
+32 to +122 (0 to 50); Operating temperature may be increased to 122 °F (50 °C with a 10%
derating of the output power)
Storage Temperature, °F
(°C)
-4 to +140 (-20 to 60) ( contain batteries will be from -15 to 40 °C.)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 10,000 ft. (3000 m) at 77 ºF (25 ºC) without derating
Audible Noise <46 dBA max @ 3 ft. (1 m) front and sides <43 dBA max @ 3 ft. (1 m) rear
Agency
Safety
UL-1778 (Fifth Edition), C-UL listed, IEC 62040-1: 2008 (First Edition) + Am 1:2013, EN 62040-1:2008+A1:2013
Transportation ISTA Procedure 1A
Surge Immunity ANSI C62.41 Category B
RFI/EMI CISPR22 Class A (RFI)/ FCC Part 15 (Class A)
*Only these models are available in the ASIA PACIFIC region.
Table 7-2 UPS Specifications, 1500 VA and 2000 VA Models
MODEL GXT5- 1500IRT2UXL* 1500IRT2UXLE 2000IRT2UXL* 2000IRT2UXLE
RATING 1500 VA/1500 W
2000 VA/2000 W
Dimensions, D×W×H, in. (mm)
Unit 18.5 × 16.9 × 3.4 (470 × 430 × 85)
Shipping 24.3 ×22.4 x 10.3 (617 x 570 x 262)
Weight, kg (lb)
Unit
21 (46.2)
Shipping
28 (61.6)
25.5 (56.1) 28 (61.6) 25.5 (56.1)
Input AC
Voltage Range (typical) 230 VAC nominal; variable based on output load
90% ~ 100% loading 168 to 288 VAC
70% ~ 90% loading 150 to 288 VAC
50%~70% loading 115 to 288 VAC
0%~50% 115 to 288 VAC
Frequency 40 Hz to 70 Hz; Auto Sensing
Input Power Cord C14 C20

Liebert Vertiv GXT5 Specifications

General

Output Voltage	230V
Topology	Double Conversion Online
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Battery Type	Valve Regulated Lead Acid (VRLA)
Communication Ports	USB, RS-232
Efficiency	Up to 95%
Typical Recharge Time	3 hours to 90%
Storage Temperature	-15°C to 40°C
Humidity	0% to 95% non-condensing
