Vertiv | Liebert® GXT5™ | Installer/User Guide 53
Chapter 4: Operation and Display Panel
The operation/display panel includes LED indicators, function keys, and an LCD interface to congure and
control UPS operation.
Figure 4-1 Touchscreen Control Panel components
ITEM DESCRIPTION
1 Run indicator LED, see LED Indicators on page 54.
2 Alarm indicator LED, see LED Indicators on page 54.
3 Power button, see Table 4-1 on the next page.
4 Menu keys, see Table 4-1 on the next page.
5 LCD panel.

Liebert Vertiv GXT5 Specifications

General

Output Voltage	230V
Topology	Double Conversion Online
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Battery Type	Valve Regulated Lead Acid (VRLA)
Communication Ports	USB, RS-232
Efficiency	Up to 95%
Typical Recharge Time	3 hours to 90%
Storage Temperature	-15°C to 40°C
Humidity	0% to 95% non-condensing
