Vertiv | Liebert® GXT5™ | Installer/User Guide 25
2.3. Installing the UPS
The UPS may be installed as a tower or in a rack, depending on available space and use considerations.
Determine the type of installation and follow the appropriate instructions. See Tower Installation or Rack
Installation below.
• When installing the UPS or making input and output connections, comply with all relevant safety
codes and standards.
2.3.1. Tower Installation
1. Take the support bases out of the accessories box.
Figure 2-1 Support bases
ITEM DESCRIPTION
1 Support bases
2 Spacers with connectors
2. If optional, Liebert® external battery cabinets will be connected, take out the spacers shipped with the
battery cabinet.
3. Connect the spacers and the support bases as shown in Figure 2-1 above. Each GXT5 requires 2 support
bases, one in the front and one in the rear.
4. Place the GXT5 and any battery cabinets on the 2 support bases.

Liebert Vertiv GXT5 Specifications

General

Output Voltage	230V
Topology	Double Conversion Online
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Battery Type	Valve Regulated Lead Acid (VRLA)
Communication Ports	USB, RS-232
Efficiency	Up to 95%
Typical Recharge Time	3 hours to 90%
Storage Temperature	-15°C to 40°C
Humidity	0% to 95% non-condensing
