GXT5 Description
12
1
.4. Removable Power Distribution Box
• PD2-108 for models ending in "N" only (North America)
• PD2-200
• PD2-201
• PD2-202
• PD2-204 for models ending in "E" only (European Union)
The 5-kVA to 10-kVA models ship with the POD installed. This POD includes the input circuit breaker for the
UPS, and the features for each POD are detailed in the following gures.
Figure 1-9 PD5-CE6HDWRMBS for GXT5-5000/6000IRT5UXLN (XLE)
ITEM DESCRIPTION
1 POD Panel view (on rear of unit)
2 POD inner-surface view
3 Quick connect
The 16-kVA and 20-kVA models do not ship with an installed power-distribution box (POD). The optional PODs
for the 16-kVA and 20-kVA models are:
