Vertiv | Liebert® GXT5™ | Installer/User Guide 105
Chapter 7: Specifications
Table 7-1 UPS Specifications, 750 VA and 1000 VA models
MODEL GXT5- 750IRT2UXL* 750IRT2UXLE 1000IRT2UXL* 1000IRT2UXLE
RATING 750 VA/750 W 1000 VA/1000 W
Dimensions, D×W×H, in. (mm)
Unit 15.7 x 16.9 x 3.4 (400 x 430 x 85)
Shipping 24.3 x 22.4 x 10.3 (617 x 570 x 262)
Weight, kg (lb
)
Unit
16.5 (36.3)
Shipping
23.5 (51.7) 21 (46.2) 23.5 (51.7) 21 (46.2)
Input AC
Voltage Range (typical) 230 VAC nominal; variable based on output load
90% ~ 100% loading 168 to 288 VAC
70% ~ 90% loading 150 to 288 VAC
50%~70% loading 115 to 288 VAC
0%~50% 115 to 288 VAC
Frequency 40 Hz to 70 Hz; Auto Sensing
Input Power Cord C14
Output AC
Output Receptacles C13 × 8
Voltage 200/208/220/230/240 VAC (user-congurable); ±3%
Waveform Sine wave
Utility (AC) Model
Overload
>200% for 250 ms; 150 to 200% for 2 seconds
125 to 150% for 50 seconds; 105 to 125% 60 seconds
Internal Battery Charger
Charger Current, A default 2.2 A; Maximum 8 A
Battery Parameters
Type Valve-regulated, non-spillable, lead acid
Qty×V×Rating 3 × 12V × 9.0 Ah
Battery Mfr./Part# LEOCH DJW12-9.0
Back-up time See Battery Run Times on page 118.
Recharge Time
3 Hours to 90% capacity after full discharge with 100% load till UPS auto-shutdown (Internal
Batteries Only)
Bypass Parameters
Upper-limit selections +10%, +15%, +20%; default +10%.
Lower-limit selections -10%, -15%, -20%; default -15%
Disable-bypass operation When the input frequency prevents synchronous operation.

Liebert Vertiv GXT5 Specifications

General

Output Voltage	230V
Topology	Double Conversion Online
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Battery Type	Valve Regulated Lead Acid (VRLA)
Communication Ports	USB, RS-232
Efficiency	Up to 95%
Typical Recharge Time	3 hours to 90%
Storage Temperature	-15°C to 40°C
Humidity	0% to 95% non-condensing
