Liebert Vertiv GXT5 User Manual

Operation and Display Panel56
4.2.2. Main Menu
To access the main menu, press Enter while at the ow screen. Table 4-3 below, describes the menu options,
and Figure 4-4 below, describes the display.
Use the arrow buttons to select the sub-menu options, and press Enter to open the sub menu. Press ESC to
return to the ow.
Table 4-3 Menu Options
SUB MENU DESCRIPTION
Status
Voltage, current, frequency, and parameters for UPS components, see Status Screen on the facing
page.
Settings Display and system parameter settings, see Settings Submenu on page 60.
Control UPS controls, see Control Screen on page 69.
Log Current alarms and event history, see Log Screen on page 71
About Product and network information, see About Screen on page 74.
Maintenance Service-only, service-password protected page for use only by Vertiv service representatives.
Figure 4-4 Mai
n Menu
ITEM DESCRIPTION
1 ECO-mode indicator
2 Ambient Temperature
3 Date and Time

Liebert Vertiv GXT5 Specifications

General

Output Voltage	230V
Topology	Double Conversion Online
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Battery Type	Valve Regulated Lead Acid (VRLA)
Communication Ports	USB, RS-232
Efficiency	Up to 95%
Typical Recharge Time	3 hours to 90%
Storage Temperature	-15°C to 40°C
Humidity	0% to 95% non-condensing
