Vertiv | Liebert® GXT5™ | Installer/User Guide 23
Chapter 2: Installation
Do not start the UPS until after the installation is nished, the system is commissioned by an authorized
engineer, and the external-input circuit breakers are closed.
Warning: Risk of electric shock
Can cause equipment damage, injury and death. Before beginning installation, verify that all external overcurrent
protection devices are open (O), and that they are locked-out and tagged appropriately to prevent activation
during the installation, verify with a voltmeter that power is O and wear appropriate, OSHA-approved
personal protective equipment (PPE) per NFPA 70E. Failure to comply can cause serious injury or death. Before
proceeding with installation, read all instructions. Follow all local codes.
2.1. Unpacking and Inspection
Unpack the UPS and conduct the following checks:
• Inspect the UPS for shipping damage. If any shipping damage is found, report it to the carrier and your local
Vertiv representative immediately.
• Check the accessories included against the packing list. If there is any discrepancy, contact your local Vertiv
representative immediately.
Liebert GXT5 UPS - AP Packing list includes the following items (750 VA to 3000 VA):
• Terminal block communications terminal
• For 750 VA - 1500 VATION
• USB Cable - one, 2 m (6.56 ft) long
- 10A IEC C13 C14 Output cable-two, 2 m (6-1/2 ft.) long
- BS 1363 (UK) to IEC C13 Input cord-one, 2.5 m (8.20 ft.) long
- German plug IEC60320 C13 Input cable-one, 2.5 m (8.20 ft.)
long (Applicable for ‘E’ models)
- Australia type A to SAA Input cord -one, 2.5 m (8.20 ft.) long
(Except for E models)
• Cable Strain Relief—two pieces
• Rack mounting hardware, including
screws, handles and mounting rail kit
(not included with model numbers
ending with an “E”)
• Plastic tower stand sets—two (four
pieces)
• For 2000 VA - 3000 VA
• Printed Quick Start Guide
- 10A IEC C13 C14 Output cable-three, 2 m (6-1/2 ft.) long
- BS 1363 (UK) to IEC C20 Input cord -one, 2.5 m (8.20 ft.) long
- German plug IEC60320 C19 Input cable-one, 2.5m (8.20 ft.)
long (Applicable for ‘E’ models)
- Australia type A to SAA Input cord-one, 2.5m (8.20 ft.)long
(Except for ‘E’ models) description
• Warnings, Safety Instructions booklet
and WEEE recycling sheet (ISO 14001
compliance)
• USB Cable - one, 2 m (6.56 ft) long
• Cable Strain Relief—two pieces
