Installation24
Liebert GXT5 UPS - AP Packing list includes the following items (5 kVA to 10 kVA):
• Terminal block communications terminal • Mounting rail kit (not included with “E” models)
• Liebert IntelliSlot Unity card (RDU101), factory
installed (not included with “E” models)
• Power-distribution box (POD), installed on GXT5
• Panels • Support-base sets
• USB Cable
• Liebert UPS Safety and Regulatory statements
booklet
• Rack mounting hardware, including screws and
handles
• Quick Start Guide
CAUTION
The UPS is heavy (see Specifications on page 105, for the weight). Take proper precautions when lifting or
moving the unit.
2.2. Pre-installation Preparation
• Install the UPS indoors in a controlled environment, where it cannot be accidentally turned O. The
installation environment should meet the specications listed in Specifications on page 105.
• Place the UPS in an area of unrestricted air-ow around the unit, away from water, ammable liquids, gases,
corrosives, and conductive contaminants. Avoid direct sunlight.
•
Operating the UPS above 77°F (25°C) temperature reduces battery life.
2.2.1. Installation Clearances
Maintain at least 4 in. (100 mm) clearance in the front and rear of the UPS. Do not obstruct the air inlets on
the front panel and rear panel of the UPS. Blocking the air inlets reduces ventilation and heat dissipation,
shortening the service life of the unit.
