Mounted on frame
Drawing No.: 1013W4008
Service lid Service lid
Integrated hinge Integrated hinge
Removable if neededRemovable if needed
Very small built-in dimension:Very small built-in dimension:
Height: Min. 90 mm (lid can be removed)Height: Min. 90 mm (lid can be removed)
Length: +20 mm (locking system)Length: +20 mm (locking system)
Easy-mount bracketEasy-mount bracket
Release hookRelease hook
3-way cable exit3-way cable exit
