MBJ1
For use together with CBJ1 or CBJ2 or CBJC, CHJ2 and BAJ1 or BAJ2. I. e. when
combining control box, charger and battery pack MBJ1 has to be used.
MBJ2
For use together with CBJ1 or CBJ2 or CBJC, and BAJ1 or BAJ2. I. e. when
combining control box and battery pack MBJ2 has to be used.
MBJ3
For use together with CHJ2 and BAJ1 or BAJ2. I. e. when combining charger and
battery pack MBJ3 has to be used.
Depending on of what your JUMBO system consists you need to use one of the following three mounting brackets. IP protection is only valid when the
JUMBO system is mounted vertically.
All three brackets include matching screws (IPX1, IPXX and IPX5 are delivered with stainless screws). The mounting screws for the control box, charger
must be tightened with a maximum torque of 1 Nm.
4. MBJ1/2/3 (MEDLINE
®
CARELINE
®
)
