The HB200 Wireless is a Bluetooth Low Energy (BLE) hand control for the medical and beds segments.
It is available with 3 to 5 rows and locking of individual channels by using a magnet key. One LED will
function as pairing and battery indicator.
Usage
• Operation temperature: +5 °C to + 40 °C
• Storage temperature: -10 °C to + 50 °C
• Relative humidity: 20% to 80% non-condensing
• Operation temperature: +5 °C to + 40 °C
• Storage temperature: -10 °C to + 50 °C
• Relative humidity: 20% to 80% non-condensing
• Atmospheric pressure: 700 to 1060 hPa
• Approvals: IEC 60601-1
IEC 60601-1-6
IEC 60601-1-2
ANSI/AAMI ES60601-1
CSA CAN/CSA-C22.2 NO. 60601-1
RED 2014/53/EU
FCC Part 15.249
IC RSS247
Telec MIC.
• Compatibility: All OpenBus
TM
BLE control boxes
16. HB200 (MEDLINE
®
CARELINE
®
)
Functionality
Locking is possible with/without the magnet and pressing a key on the HB200.
Please note that the way to lock must be defined in the control box software.
As an example to lock with magnet: hold the magnet key over the marking ( ) and
press an odd key number (Typically the up arrow). To unlock a row use the magnet
key and press an even number (Typically the down arrow).
Battery
The battery in the HB200 is a standard CR2032 coin cell battery.
Battery lifetime
With a usage of 140 sec/day, the HB200 will last approximately two years.
Changing the battery
To change the HB200 battery, open the battery cover on the back using a coin or a similar
tool to turn the arrow counterclockwise from the locked state to the unlocked state.
Battery cover:
It is possible to order extra battery covers.
Battery cover ordering no. SA1031W9012
Magnet key
Remember to order magnet key:
Magnet key - ordering no. 0858008 (RAL 7035 light grey)
Low battery indication - When the battery power level falls below 20%, the LED
will flash 4 times when a key is pressed.
New battery indication - When the battery has been changed, the LED will be lit
for 4 seconds after the first keypress.
