Page 279 of 295
The control box COL50 is a part of the LIFT50 product series
specially developed for patient lifts.
LIFT50 is a complete system consisting of the control box
COL50, a battery BAL50 and an external charger CHL50 in a
flexible solution. Combined with one or more actuators and a
hand control, you have a complete system for modern patient
lifts.
4. COL50 (MEDLINE
®
CARELINE
®
)
Usage
• With internal charger: Nominal current draw max. 350 mA (depending on input voltage)
Power consumption (standby) max. 0.5 W power (depending on input voltage)
Input voltage range: 120-240 VAC (50/60 Hz)
Power consumption (charging) max. 30 W (depending on input voltage)
• Duty cycle: Max. 10% or 2 min. continuous use followed by 18 min. without use
• Operating temperature: +5 °C to +40 °C
• Storage temperature: -10 °C to +50 °C
• Relative humidity: 20% to 80% - non-condensing
• Atmospheric pressure: 700 to 1060 hPa
• Meters above sea level: Max. 3000 meters
• Approvals: EN IEC 60601-1
ANSI/AAMI ES60601-1
CAN/CSA-C22.2 NO. 60601-1
EN IEC 60601-1-2
RED (EU)
FCC ID (US)
IC ID (Canada)
Telec (Japan)
Instructions for use
• Default functionality – when charging, the COL50 will not be able to operate any actuators.
• It is not possible to use other battery types than BAL50 with the COL50.
• Use only original LINAK mains cables to ensure proper connection to internal charger.
