Page 157 of 295
The LINAK control box CO65 offers a consolidated range of unprecedented features – all utilising
standardised technology, interfaces and compatibility.
The CO65 for LINAK actuators is intended for the control of, for example, hospital bed movement.
Equipped with 280 W SMPS, excellent and well thought-out cable management as well as multiple
easy mounting options, this control box opens up a wide range of application possibilities for the
provident hospital and care products manufacturer.
LED indicator
CO65 is equipped with a green LED for indication of mains power connected. When the CO65 is
connected to mains, the LED is green. Connected only to battery, the LED is off.
15. CO65 (MEDLINE
®
CARELINE
®
)
Usage
• Operation temperature: +5 °C to +40 °C
• Storage temperature: -10 °C to +50 °C
• Relative humidity: 20% to 80% - non-condensing
• Atmospheric pressure: 700 to 1060 hPa (3000 m)
• Meters above sea level: Max. 2000 meters
• Approvals: IEC60601-1 edition 3.1
ANSI/AAMI ES60601-1:2005/(R) 2012
CSA CAN/CSA-C22.2 NO. 60601-1:14
Acoustic signal functionality:
The buzzer will make a warning, when a button on the hand control is pressed, and the battery state of charge is low. The buzzer can also be activated
by the control box to signal other conditions. This must be specified in the control box software.
Connected to MAINS
LED colour Indication of operation
Green
On mains, not activated by hand or foot control.
The system is working ok and is ready for normal operation.
Yellow
On mains, not activated by hand or foot control.
The system is defective and should not be operated.
Yellow On mains, activated by hand or foot control.
The system is working.
Not connected to mains but with BATTERY back-up
LED colour Indication of operation
Orange On battery, activated by hand or foot control.
The system is working.
No LED
On battery, not activated by hand or foot control.
or CO61 not connected to mains.
