Mounted on frame:
Release hookRelease hook
Easy-mount bracketEasy-mount bracket
3-way cable exit3-way cable exit
Very small built-in dimension:Very small built-in dimension:
Height: min. 80 mm (lid can be removed)Height: min. 80 mm (lid can be removed)
Length: + 20 mm (locking system)Length: + 20 mm (locking system)
Service lidService lid
Integrated hingeIntegrated hinge
Removable if neededRemovable if needed
Drawing No.: 1013W4008
