Locking of cable mechanism
1. Align the locking mechanism
with the MJB5 Plus.
2. Press the cable locking
mechanism down until
you hear a click sound.
3. Slide the mechanism forward until you hear
another click sound.
4. MJB5 Plus with a
locked cable
mechanism.
Video guide available on
www.linak.com
Unlocking of cable locking mechanism
If a cable needs to be replaced or added, we recommend to open the cable locking mechanism
as described below and demonstrated in our video on LINAK.com - MJB5 Plus section brochures
and manuals.
Video guide available on
www.linak.com
1. Insert a pin or screwdriver with
a diameter of 3.5 to 4 mm.
2. Pull downwards until a click sound is heard.
Repeat this for the other locking hole.
3. The cable mechanism is now unlocked.
