Unlocking of cable locking mechanism
If a cable needs to be replaced or added, we recommend to open the cable locking mechanism
as described below and demonstrated in our video on LINAK.com - MJB5 Plus section brochures
and manuals.
Video guide available on
www.linak.com
1. Insert a pin or screwdriver with
a diameter of 3.5 to 4 mm.
2. Pull downwards until a click sound is heard.
Repeat this for the other locking hole.
3. The cable mechanism is now unlocked.
Locking of cable mechanism
1. Align the locking mechanism
with the MJB5 Plus.
2. Press the cable locking
mechanism down until
you hear a click sound.
3. Slide the mechanism forward until you hear
another click sound.
4. MJB5 Plus with a
locked cable
mechanism.
Video guide available on
www.linak.com
