Feedback specifications
E1 (power switch) F6 (potentiometer)
1 GND
2 NC
3 M+ (motor/power)
4 Potentiometer feedback
5 VCC
6 M- (motor/power)
Feedback specification
VCC max. 5 V
Resistor 8 - 12 kΩ
Linearity (± 2% of *maximum stroke) ± 5.8 mm
Precision (± 5% of *maximum stroke) ± 14,5 mm
Calculation of maximum stroke length
Gearing 4
Spindle pitch 5 mm / rev
Total turns on potentiometer 14.5 turns
*maximum stroke 280 mm
E2 (signal) F6 (potentiometer)
1 GND (common EOS*)
2 VCC
3 M+ (Motor/Power)
4 Potentiometer feedback
5 EOS* IN/OUT
6 M- (Motor/Power)
* EOS equal to end of stroke
Feedback specification LINAK A/S system
Linearity (± 2% of *maximum stroke) ± 5.8 mm
Precision (± 5% of *maximum stroke) ± 14,5 mm
Calculation of maximum stroke length
Gearing 4
Spindle pitch 5 mm/rev
Total turns on potentiometer 14.5 turns
*maximum stroke 280 mm
