Linak Inline LA20

Page 97 of 295
T130
Connections 5: Motor
6: Mains through 1
Female connection top entry,
male connection side entry
7: Minifit through
3: Mains through 1
Female connection top entry,
male connection side entry
4: Minifit through
T140
Connections 5: Motor
6: Mains through 2
Male connection top entry,
female connection side entry
7: Minifit through
3: Mains through 2
Male connection top entry,
female connection side entry
4: Minifit through
T230
Connections 5: Motor
6: Mains through 1
Female connection top entry,
male connection side entry
7: HB through
3: Mains through 1
Female connection top entry,
male connection side entry
4: HB through
