Lucent Technologies Galaxy Power System 4848/100
12 - 12 Troubleshooting Preparations Issue 5 June 2000
Reference Figures, continued
AC Input
Figure 12-8: AC Input Panel and Rectifier Connection
HIGH VOLTAGE BEHIND COVER.
RISK OF SEVERE INJURY OR DEATH.
TURN OFF AC AT BRANCH CIRCUIT
BOX. KEEP COVER IN PLACE TO AVOID
ELECTRICAL HAZARD.
WARNING
RECTIFIER RECTIFIER RECTIFIER RECTIFIER
1234
1
1
2
2
3
3
4
4
AC Input
Rectifier
AC Input
DC Output
Ground
Data Pins for
Communication
Back of Rectifier
Plugs into Mating
Connector on Shelf
ABC
Phase 1
Phase 2
Phase 3
595A
595B
Measure between:
Phase Voltage Range
A and B
B and C
C and A
320Vac - 530Vac
176Vac - 254Vac
1234
AC Circuit Breakers for
Rectifiers
