Lucent Technologies Galaxy Power System 4848/100
6 - 4 Battery Connection Panels Issue 5 June 2000
Figure 6-5: H569-434 G35 (ED83143-30 Group 42)
Battery Connection Panel
Alarm/Terminal
Card
(1) NH3 Fuse Holder
Connects to
Charge Return Bus
6" REF
(152mm)
600A Shunt
Figure 6-6: H569-434 G37/38 (ED83143-30 Group 60/61)
Battery (OLE) Connection Panel
Alarm/Terminal Card
(3) 600A Fuses
(3) 1000A Shunts
(1) 1200A Contactor
and Contactor Control
Board (G60 only)
M10 Connections
Connects to
Charge Return Bus
15" REF
(381mm)
Note: For more information, refer
to the OLE Product Manual,
Select Code 167-792-200
