Lucent Technologies Galaxy Power System 4848/100
9 - 4 Specifications Issue 5 June 2000
Rectifiers
Table 9-B: 595 Series Rectifier Specifications
Electrical
Output Voltage 52Vdc typical
Equalize Voltage 65Vdc typical
Output Voltage Adjustment 44-58Vdc float/boost
58-65Vdc equalize mode
Regulation (with controller) ±.5%
High Voltage Shutdown
(selected by controller)
Float/boost 44-60Vdc (56Vdc default)
Equalize 44-67Vdc (65Vdc default)
Backup High Voltage Shutdown Float/boost 59-60Vdc (59.5Vdc nominal)
Equalize 65.5-66.5Vdc (66Vdc nominal)
Thermal Alarm
595A2 65°C (63-67°C range
1
)
595B2 60°C (58-63°C range
1
)
1
Actual range due to tolerance in component and
circuit
Ripple 100mVrms
Noise <2mV psophometric
Permanent Overload 220Adc
Current Limit Set Point 60Adc - 220Adc
(60Adc - 100Adc in equalize)
Nominal Input Voltage
595A2 Rectifier
380-480Vac, 3-wire plus ground
Nominal Input Voltage
595B2 Rectifier
200-240Vac, 3-wire plus ground
Input Voltage Range per phase
595A2 Rectifier
320Vac - 530Vac
Input Voltage Range per phase
595B2 Rectifier
176Vac - 254Vac
Input Current
595A2 Rectifier
20Aac @ 480Vac
25Aac @ 380Vac
Input Current
595B2 Rectifier
40Aac @208Vac
35Aac @240Vac
Frequency Range 47 - 63 Hz
Power Factor >0.92 @ 50% to 100% load
Total Harmonic Distortion <34% @ 50% to 100% load
