Lucent Technologies Galaxy Power System 4848/100
2 - 6 System Description Issue 5 June 2000
Architecture, continued
Figure 2-5: Centralized Architecture Initial and Growth Cabinets
Galaxy
ESD
WRISTSTRAP
GROUNDING
POINT
Initial Cabinet Growth Cabinet
