Lucent Technologies Galaxy Power System 4848/100
12 - 10 Troubleshooting Preparations Issue 5 June 2000
Reference Figures, continued
Rectifier During normal operation, the rectifier’s green ON LED will be lit and
the display will show the rectifier’s output current.
Figure 12-6: Rectifier Display
ON
ON
OFF
ID
CURRENT
STBY
ALM
LIM
FAN ALM
EQL
200A/48V
ON
ON
OFF
ID
CURRENT
STBY
ALM
LIM
FAN ALM
EQL
200A/48V
Status Indicators
