Lucent Technologies Galaxy Power System 4848/100
7 - 2 DC Distribution Panels Issue 5 June 2000
Figure 7-1: H569-434 G40/45/50/55 (ED83143-30 G11/13)
400A DC Distribution Panel
Alarm Card
13 Positions for U.S.
Plug-in Circuit Breakers (3-100A)
or Fuse Holders
(TPA Fuses, 5-30A)
Connects to
Charge Return Bus
6" REF
(152mm)
Figure 7-2: H569-434 G41/46/51/56 (ED83143-30 G12/14)
400A DC Distribution Panel
Alarm Card
21 Positions for U.S.
Plug-in Circuit Breakers (3-100A)
or Fuse Holders
(TPA Fuses, 5-30A)
Connects to
Charge Return Bus
9" REF
(229mm)
