Lucent Technologies Galaxy 4848/100 - DIST Alarm LED; Table 14-D: Distribution Alarms

Lucent Technologies Galaxy Power System 4848/100
14 - 10 Troubleshooting Millennium Systems Issue 5 June 2000
DIST Alarm LED
Table 14-D: Distribution Alarms
(See Figures 12-9 and 12-10)
Controller
LED
Controller
Alarm
Status
Millennium
Controller Display
Other
Indication(s)
Possible
Problem(s)
Possible Solution(s)
DIST MAJ External Fuse
Major
Alarm LED
on dc
distribution
panel is lit.
DC load fuse or
circuit breaker
has operated.
Replace fuse or reset
circuit breaker.
DIST*
*Alarm
must be
configured
to turn on
the DIST
LED; not
a factory
default.
MAJ Contactor 2 (or 3)
Open
Red LED on
contactor
drive board
is lit.
Contactor is
open:
•Open has been
initiated by
controller.
•Open has been
initiated
manually.
1. Follow instructions on
the label adjacent to the
contactor drive board
(see Figure 12-10).
2. If the problem is not
corrected, call your
local RTAC
representative.
DIST*
*Alarm
must be
configured
to turn on
the DIST
LED; not
a factory
default.
MAJ Contactor 2 (or 3)
Fail
-- Contactor or
drive board has
failed.
Call your local RTAC
representative.
